Handling Robots
The Handling Robot is an advanced automated solution designed to streamline material handling tasks across various industries. Equipped with state-of-the-art sensors, precise actuators, and sophisticated software, this robot ensures efficient, accurate, and safe handling of materials, contributing to enhanced productivity and reduced labor costs.
Technical Parameters
| Basic Parameters | Degrees of Freedom | 4 |
|---|---|---|
| Specified Load | 8kg | |
| Humidity | 0~50℃ | |
| Working Environment Temperature | 20%~80%RH(no condensation) | |
| Repeatability | ±0.8mm | |
| Installation Method | ground | |
| Battery Capacity | 2.5 KW |
| Range of Motion | J1 | ±170° |
|---|---|---|
| J2 | -３８° ~ +７８° | |
| J3 | -９０° ~ +１０° | |
| J4 | ±360° |
| Maximum Speed | J1 | 150°/s |
|---|---|---|
| J2 | 149°/s | |
| J3 | 225°/s | |
| J4 | 375°/s |
| Protection Grade | Protection Grade | body IP53,wrist Ip54 |
|---|
| Other | Main Purpose | handling/ palletizing/ load and unload/ |
|---|
